Set 481

For first time visitors I recommend this archive for some of my best posts.





2797. 4-3/4" long, sent in by a visitor who is looking to identify this device, text on it reads "M.D. Kharegat, Resectorscope, E.R. Watts & Son. Ltd. London":

Larger image



Larger image



Larger image



Larger image



Larger image



Larger image



Larger image























2798. 6" diameter:

Larger image






Larger image






















2799. Around 10" long:

Larger image































2800. Approximately 14" long:

Larger image



Larger image
































2801. About 12" long, take a look at Neatorama for more guesses and a chance to win one of their funny T-shirts:
































2802. 7" long:

Larger image

















Answers:


2797. This is a surveying instrument that was patented in Great Britain in 1946, here is one of its uses as described in the patent:
"One problem which frequently arises and which cannot be efficiently solved by other instruments is the production of straight lines over undulating country such for example as the determination of a point on the top of an embankment in line with two points on either side of the embankment. Holding the instrument with the axis of the pivot horizontal and the mirrors set at a convenient angle, the user moves to and fro on the top of the embankment until the close relationship along one edge are adapted to be set at an angle to one another with their planes intersecting, a guide line being provided on each mirror at right angles to the axis of intersection, the guide lines being in the same plane."

Larger image




Larger image























2798. Made by the Chicago Tire Lug Company, two of these devices could be attached to each rear tire to help get an automobile out of sand, mud, or snow:




Larger image





















2799. This is a fishing rod holder, it would have been pushed into the ground and then the rod and reel would be placed in the bracket:

Larger image



























2800. A pipe and nut wrench, patent number 618,313:

Larger image



Larger image




























2801. This is a homemade hammer, considering its weight, it was probably used for moving heavy wooden pieces into place or driving barn pegs, though it could have been used for any other appropriate task.




























2802. A Berry Staple Remover for use on upholstery, patent number 3,310,288:







Larger image










Are you interested in Old Tools and Tool Collecting? Want to learn more about tools, and meet some great people who have the same interests? Please take a minute to check out the Mid-West Tool Collectors Web Site at this link: www.mwtca.org.























To submit photos, send them to the address in my profile, please include dimensions, any text on the item, and where it was found.













Last week's set is seen below, click here to view the entire post.








More discussion and comments on these photos can be found at the newsgroup rec.puzzles.
